Easy to operate, remote-controlled pumping.
Available in models of 14m, 18m, 20m, 23m and 25m
---------------------------------------------------------------------------------
Technical Parameters (Model: SMBCP23)
1. Main Performance
- Max theoretical concrete output: 60 M³/h
- Max concrete pumping pressure: 7 Mpa
- Distribution valve type: S valve
- Concrete cylinder diameter x stroke: Ф180×1300 mm
- Hopper capacity x feeding height: 500 L × 1500 mm
2. Boom Parameters
- Boom vertical height: 22.7 m
- Distribution radius: 20.3 m
- Length of first jib: 6.37 m
- Length of second jib: 5.57 m
- Length of third jib: 5.47 m
- Length of fourth jib: 3.2 m
- Concrete delivery pipe: 125 mm
- Rotation angle: 270 °
- Boom control: wireless
- Max aggregate size: 40 mm
3. Power System
- Diesel engine model: Weichai
- Rated power: 97 kw
- Rated rotated speed: 2000 rpm
4. Hydraulic System
- Hydraulic oil circuit form: Open circuit
- Pumping main oil pump: Kawasaki K3V112S
- Pumping system oil pressure: 30 Mpa
- Mixing system oil pressure: 8 Mpa
5. Other Parameters
- Travel diesel engine: Yunnei
- Travel diesel engine power: 66 Kw
- Travel gearbox: 280
- Tires: 8.25*16
- Steering: Hydraulic power assist
- Brakes: Air brake
- Max travel speed: 40 Km/h
- Length × width × height: 8800×2250×2600 mm
- Total weight: 14500 kg
---------------------------------------------------------------------------------
Main Configuration (Model: SMBCP23)
- Pumping Diesel engine model: Weichai 97kw (China)
- Travel diesel engine model: Yunnei 66kw (China)
- Main hydraulic pump: Kawasaki K3V112 (South Korea)
- Hydraulic hose: Parker or Manuli
- Seal: Parker (US)
- Intermediate Relay: Schneider (France)
- PLC unit: Omron (Japan) or Siemens
- Valve group: BEIJINGHUADE and Shanghai-made
- Lubrication system: Fully-Automatic hydraulic
- Remote control: Wireless
- Buttons: Made in China
